ISSR_PROT_PROF SAP table for – ISSR: A-Log Profile (Für Anzeige der Protokolle)

Here we would like to draw your attention to ISSR_PROT_PROF table in SAP. As we know it is being mainly used with the SAP FS-SR (Regulatory reporting for insurance companies in FS) component which is coming under FS module (Financial Services). ISSR_PROT_PROF is a SAP standard transp table used for storing ISSR: A-Log Profile (Für Anzeige der Protokolle) related data in SAP. It comes under the package VVSRFISL.

SAP ISSR_PROT_PROF table

Table ISSR_PROT_PROF technical data

TableISSR_PROT_PROF
Data storingISSR: A-Log Profile (Für Anzeige der Protokolle)
ModuleFS
Sub ModuleFS-SR
SAP PackageVVSRFISL
Delivery ClassS – System table, data changes have the status of program changes
ComponentEA-FINSERV
Table CategoryTRANSP

SAP ISSR_PROT_PROF Table Fields

Here is the details of each fields in this SAP table. You can find the discription, data type and assigned lenth of each of the fields in ISSR_PROT_PROF table.

  • MANDT : Client
    Its a key field. Its data type is CLNT (Character with length 3) with field length 3
  • USER_PROFILE : User Name
    Its a key field. Its data type is CHAR (Character String) with field length 12
  • PROFIL_NR : Counter
    Its a key field. Its data type is NUMC (Character String with Digits Only) with field length 3
  • ACTIVE : Kennzeichen: Eintrag aktivieren
    Its data type is CHAR (Character String) with field length 1
  • USE_GRID : Application Log: Use grid control for output
    Its data type is CHAR (Character String) with field length 1
  • NO_TOOLBAR : Application Log: Hide toolbar in ALV grid
    Its data type is CHAR (Character String) with field length 1
  • START_COL : Application Log: Dialog box coordinates
    Its data type is INT4 (Four-byte integer – Dictionry type INT4) with field length 10
  • START_ROW : Application Log: Dialog box coordinates
    Its data type is INT4 (Four-byte integer – Dictionry type INT4) with field length 10
  • END_COL : Application Log: Dialog box coordinates
    Its data type is INT4 (Four-byte integer – Dictionry type INT4) with field length 10
  • END_ROW : Application Log: Dialog box coordinates
    Its data type is INT4 (Four-byte integer – Dictionry type INT4) with field length 10
  • POP_ADJST : Application Log: Adjust popup height
    Its data type is CHAR (Character String) with field length 1
  • SHOW_ALL : Application Log: Display all messagee immediately
    Its data type is CHAR (Character String) with field length 1
  • MESS_MARK : Applicationn Log: Messages in list selectable
    Its data type is CHAR (Character String) with field length 1
  • CWIDTH_OPT : Application Log: Optimize message list column width
    Its data type is CHAR (Character String) with field length 1
  • HEAD_TEXT : Application Log: Tree: Hierarchy column heading text
    Its data type is CHAR (Character String) with field length 50
  • HEAD_SIZE : Application Log: Tree: Hierarchy column width
    Its data type is INT4 (Four-byte integer – Dictionry type INT4) with field length 10
  • ROOT_TEXT : Application Log: Tree: Root node text
    Its data type is CHAR (Character String) with field length 50
  • TREE_SIZE : Application Log: Tree: Size of Tree Control in CHAR
    Its data type is INT4 (Four-byte integer – Dictionry type INT4) with field length 10
  • TREE_ONTOP : Application Log: Tree: Display above messages
    Its data type is CHAR (Character String) with field length 1
  • TREE_ADJST : Application Log: Tree: Adjust height if TREE_ONTOP = X
    Its data type is CHAR (Character String) with field length 1
  • EXP_LEVEL : Application Log: Tree: Expand to level
    Its data type is INT4 (Four-byte integer – Dictionry type INT4) with field length 10
  • BYDETLEVEL : Application log: Construct hierachy by DETLEVEL
    Its data type is CHAR (Character String) with field length 1
  • TREE_NOMSG : Application Log: No message data required in tree
    Its data type is CHAR (Character String) with field length 1
  • NOT_EMPTY : Application Log: Do not show empty branches
    Its data type is CHAR (Character String) with field length 1
  • DIS_PROBCLASS : ISSR: Problemklassenanzeigevariante
    Its data type is CHAR (Character String) with field length 1
