RSZRANGE SAP table for – Selection specification for an element

Here we would like to draw your attention to RSZRANGE table in SAP. As we know it is being mainly used with the SAP BW-BEX (Business Explorer in BW) component which is coming under BW module (Business Warehouse). RSZRANGE is a SAP standard transp table used for storing Selection specification for an element related data in SAP. It comes under the package RSZ.

SAP RSZRANGE table

Table RSZRANGE technical data

TableRSZRANGE
Data storingSelection specification for an element
ModuleBW
Sub ModuleBW-BEX-ET
SAP PackageRSZ
Delivery ClassE – System table whose data is transported with its own transport objects
ComponentSAP_BW
Table CategoryTRANSP

SAP RSZRANGE Table Fields

Here is the details of each fields in this SAP table. You can find the discription, data type and assigned lenth of each of the fields in RSZRANGE table.

  • ELTUID : BW: Unequivocal ID in room and time
    Its a key field. Its data type is CHAR (Character String) with field length 25
  • OBJVERS : Object version
    Its a key field. Its data type is CHAR (Character String) with field length 1
  • IOBJNM : InfoObject
    Its a key field. Its data type is CHAR (Character String) with field length 30
  • ENUM : Sequence Number
    Its a key field. Its data type is NUMC (Character String with Digits Only) with field length 4
  • SOTP : Purpose in the Selection Object
    Its data type is CHAR (Character String) with field length 1
  • FACIOBJNM : InfoObject
    Its data type is CHAR (Character String) with field length 30
  • ATTRINM : InfoObject
    Its data type is CHAR (Character String) with field length 30
  • TERM : Sequence Number
    Its data type is NUMC (Character String with Digits Only) with field length 4
  • FACTOR : Sequence Number
    Its data type is NUMC (Character String with Digits Only) with field length 4
  • FACTORTYPE : Type of factor for requirements and exceptions
    Its data type is NUMC (Character String with Digits Only) with field length 1
  • .INCLUDE : Enhanced range structure for Report Builder
  • SELTP : Selection type
    Its data type is NUMC (Character String with Digits Only) with field length 1
  • .INCLUDE : Range table in brain
  • SIGN : SIGN field in creation of SELECT-OPTIONS tables
    Its data type is CHAR (Character String) with field length 1
  • OPT : Operator in Select Options and other Expressions
    Its data type is CHAR (Character String) with field length 2
  • LOW : Dim: Field for a User-Defined Characteristic Value
    Its data type is SSTR (Short Character String of Variable Length) with field length 1333
  • HIGH : Dim: Field for a User-Defined Characteristic Value
    Its data type is SSTR (Short Character String of Variable Length) with field length 1333
  • LOWFLAG : Flag for ‘typing’ an entry
    Its data type is NUMC (Character String with Digits Only) with field length 1
  • SHIFTLOW : Shift of the variable (&VAR+n)
    Its data type is INT4 (Four-byte integer – Dictionry type INT4) with field length 10
  • HIGHFLAG : Flag for ‘typing’ an entry
    Its data type is NUMC (Character String with Digits Only) with field length 1
  • SHIFTHIGH : Shift of the variable (&VAR+n)
    Its data type is INT4 (Four-byte integer – Dictionry type INT4) with field length 10
  • HIENM : Hierarchy name
    Its data type is CHAR (Character String) with field length 30
  • HIENMFLAG : Flag for ‘typing’ an entry
    Its data type is NUMC (Character String with Digits Only) with field length 1
  • VERSION : BW: Unequivocal ID in room and time (numbers and letters)
    Its data type is CHAR (Character String) with field length 25
  • VERSIONFLAG : Flag for ‘typing’ an entry
    Its data type is NUMC (Character String with Digits Only) with field length 1
  • DATETO : BW: Unequivocal ID in room and time (numbers and letters)
    Its data type is CHAR (Character String) with field length 25
  • DATETOFLAG : Flag for ‘typing’ an entry
    Its data type is NUMC (Character String with Digits Only) with field length 1
  • THJT : Key Date Derivation Type
    Its data type is CHAR (Character String) with field length 10
  • WAERS : Currency Key
    Its data type is CUKY (Currency key for a currency field) with field length 5
  • MEEHT : Unit key
    Its data type is UNIT (Unit key for a Quantity field) with field length 3
  • CHAPRSNT : Display for Characteristics and Units
    Its data type is CHAR (Character String) with field length 1
  • ALERTLEVEL : Alert priority
    Its data type is NUMC (Character String with Digits Only) with field length 2
