RSRA_MX_LOG SAP table for – Log Table for the Batch Run of MDX Precalculation

Here we would like to draw your attention to RSRA_MX_LOG table in SAP. As we know it is being mainly used with the SAP BW-BEX (Business Explorer in BW) component which is coming under BW module (Business Warehouse). RSRA_MX_LOG is a SAP standard transp table used for storing Log Table for the Batch Run of MDX Precalculation related data in SAP. It comes under the package RSRB.

SAP RSRA_MX_LOG table

Table RSRA_MX_LOG technical data

TableRSRA_MX_LOG
Data storingLog Table for the Batch Run of MDX Precalculation
ModuleBW
Sub ModuleBW-BEX-ET
SAP PackageRSRB
Delivery ClassE – System table whose data is transported with its own transport objects
ComponentSAP_BW
Table CategoryTRANSP

SAP RSRA_MX_LOG Table Fields

Here is the details of each fields in this SAP table. You can find the discription, data type and assigned lenth of each of the fields in RSRA_MX_LOG table.

  • JOBNAME : Background job name
    Its a key field. Its data type is CHAR (Character String) with field length 32
  • JOBCOUNT : Job ID
    Its a key field. Its data type is CHAR (Character String) with field length 8
  • SETTINGNM : Technical Name of Report Agent Setting
    Its a key field. Its data type is CHAR (Character String) with field length 30
  • STEP : Numbering for one-dimensional drilldown
    Its a key field. Its data type is NUMC (Character String with Digits Only) with field length 4
  • TIMESTMP : UTC Time Stamp in Short Form (YYYYMMDDhhmmss)
    Its data type is DEC (Packed number (number with fixed number of decimal places)) with field length 15
  • STEP_TIME : UTC Time Stamp in Short Form (YYYYMMDDhhmmss)
    Its data type is DEC (Packed number (number with fixed number of decimal places)) with field length 15
  • OBJECT_TYPE : Object Type of the Reporting Agent
    Its data type is CHAR (Character String) with field length 30
  • OBJECT_ID : Technical name of object
    Its data type is CHAR (Character String) with field length 30
  • PARENT_TYPE : Object Type of the Reporting Agent
    Its data type is CHAR (Character String) with field length 30
  • PARENT_ID : Technical name of object
    Its data type is CHAR (Character String) with field length 30
  • REFOBJ_TYPE : Object Type of the Reporting Agent
    Its data type is CHAR (Character String) with field length 30
  • REFOBJ_ID : Technical name of object
    Its data type is CHAR (Character String) with field length 30
  • LANGU : Language Key
    Its data type is LANG (Language key character with length 1) with field length 1
  • UNAME : User Name
    Its data type is CHAR (Character String) with field length 12
  • REQUID : Request ID (Request Number)
    Its data type is CHAR (Character String) with field length 30
  • STATUS : General Status Flag
    Its data type is CHAR (Character String) with field length 1
  • CLUSTERKEY : BW: Cluster table key
    Its data type is CHAR (Character String) with field length 32

    • RSRA_MX_LOG related tables

    • RSRA_BT_PARAM : General Parameter Table
    • RSRA_SETTINGT : Text Table for the Report Agent Settings
    • RSRA_SETTING_BB : RA Settings for Calculating Buckets
    • RSRA_ER_DRILL : Drill Characteristics for the Exception Reporting Setting
    • RSRA_ER_FOLLOWUP : Follow-Up Actions for Reporting Agent Exception Reporting
    • RSRA_BP_OBJECTS : Parts of the Batch Printing Setting
    • RSRA_MX_PARAM : Parameter Table for MDX Setting
    • RSRA_ER_PARAMT : Text Table for Parameters of ER SEttings
    • RSRA_ER_LOGN : Log Table for Batch Runs of Exception Reporting
    • RSRA_BB_PARAMT : Text Table for the BB Settings Parameters
    • RSRA_BP_RTXTH : Report Agent BP Transport Copy/Versioning of rtxth
    • RSRA_BP_RTXTF : Report Agent BP Transport Copy/Versioning of rtxth
    • RSRA_SETTING : Settings for the Report Agent
    • RSRA_SETTING_BT : RA Settings for Precalculating Templates
    • RSRA_MX_PARAMT : Text Table for Parameters of MDX Settings
    • RSRA_PACKAGE_MEM : Parts of a Report Agent Job
    • RSRA_BP_RTXTL : Report Agent BP Transport Copy/Versioning of rtxtl
    • RSRA_BC_AUTH : Display Auth. for Precalculated Templates by Redirect URL
    • RSRA_RA_PARAM : General Parameter Table
    • RSRA_PACKAGE : Scheduling Packages for the Report Agent

    RSRA_MX_LOG related transaction codes under SAP package RSRB

    • RSRAPS : Manages Page Store
    • REPORTING_AGENT : Scheduler Test Call
    • RUNSCHED : Scheduler Test Call
    • RSRAM : Reporting Agent Monitor
    • RSRAJ : Starts a Reporting Agent Job
